Display System
4K SXRD panel projection system
Display Device
Size of effective display area
0.74″ x 3
Number of pixels
26,542,080 (4096 x 2160 x 3) pixels
Projection lens
Focus
Powered
Zoom
Powered
Lens shift
VPLL-Z7013 (Bundled): Powered V ± 80%, H ± 31%
VPLL-Z7008 (Optional): Powered V ± 50%, H ± 18%
VPLL-Z7008 (Optional): Powered V ± 50%, H ± 18%
Throw ratio *1
VPLL-Z7013 (Bundled): 1.35 : 1 to 2.90 : 1
VPLL-Z7008 (Optional): 0.85 : 1 to 1.06 : 1
VPLL-Z7008 (Optional): 0.85 : 1 to 1.06 : 1
Light source
Light source
Laser diode
Light output
Light output
5,000 lm
Color light output
Color light output
5,000 lm
Contrast ratio
Contrast ratio
∞:1 (dynamic contrast)
Accepted digital signals *2
Accepted digital signals *2
VGA, SVGA, XGA, WXGA(1280×768), Quad-VGA, SXGA, 720×480/60p, 720×576/50p, 1280×720/50p, 1280×720/60p,
1920×1080/50i,1920×1080/60i, 1920×1080/24p, 1920×1080/50p, 1920×1080/60p, 3840×2160/24p, 3840×2160/25p,
3840×2160/30p, 3840×2160/50p, 3840×2160/60p, 4096×2160/24p, 4096×2160/25p, 4096×2160/30p, 4096×2160/50p,
4096×2160/60p
1920×1080/50i,1920×1080/60i, 1920×1080/24p, 1920×1080/50p, 1920×1080/60p, 3840×2160/24p, 3840×2160/25p,
3840×2160/30p, 3840×2160/50p, 3840×2160/60p, 4096×2160/24p, 4096×2160/25p, 4096×2160/30p, 4096×2160/50p,
4096×2160/60p
Color bit depth
Color bit depth
Up to 12 bit via HDMI
Input / Output
HDMI1/HDMI2 *3
Digital (RGB/Y Pb/Cb Pr/Cr)
TRIGGER1/TRIGGER2
Mini jack, DC 12 V Max. 100 mA
REMOTE
RS-232C, D-sub 9-pin (female)
LAN
RJ45, 10BASE-T/100BASE-TX
IR IN/OUT
IN:1, OUT:1 , Mini jack
USB
Type A
Acoustic noise
Acoustic noise
30dB ~ 35dB *4
Operating temperature / Operating humidity
Operating temperature / Operating humidity
5°C to 40°C (41°F to 104°F) / 20% to 80% (no condensation)
Storage temperature / Storage humidity
Storage temperature / Storage humidity
-10°C to +60°C (14°F to +140°F) / 20% to 80% (no condensation)
Power requirements
Power requirements
AC 220 V to 240 V, 6 A, 50/60 Hz (For Europe and China)
AC 100 V to 240 V, 12 A to 6 A, 50/60 Hz (For the other countries)
AC 100 V to 240 V, 12 A to 6 A, 50/60 Hz (For the other countries)
Power consumption
Power consumption
MAX. 1.2 kW
Power Consumption (Standby)
Power consumption (Standby)
0.5 W
Heat dissipation
Heat dissipation
4092 BTU/h
Dimensions (WxHxD) (without protrusions)
Dimensions (WxHxD) (without protrusions)
550 x 228 x 750 mm / 21.6 x 9.0 x 29.5 inch
Mass
Mass
Approx. 43 kg / 94 lb (including standard lens)
Approx. 40 kg / 88 lb (excluding standard lens)
Approx. 40 kg / 88 lb (excluding standard lens)
Supplied accessories
Supplied accessories
VPLL-Z7013 (Standard lens)
RM-PJ24 Remote Commander
Size AA (R6) Manganese Batteries (2)
AC Power Cord (1)
Plug holder (1)
Operating Instructions (CD-ROM)(1)
Quick Reference Manual (1)
RM-PJ24 Remote Commander
Size AA (R6) Manganese Batteries (2)
AC Power Cord (1)
Plug holder (1)
Operating Instructions (CD-ROM)(1)
Quick Reference Manual (1)
Optional accessories
Optional accessories
TDG-BT500A (3D glasses)*
VPLL-Z7008 (Short Throw Lens)
*Please contact your Sony representative for specific models available in your region.
VPLL-Z7008 (Short Throw Lens)
*Please contact your Sony representative for specific models available in your region.
Notes
*1 Display size : 16:9
*2 60p,30p,24p include 59.94/60Hz, 29.97Hz/30Hz, 23.98Hz/24Hz
*3 Both HDMI inputs are compatible with HDCP 2.2.
*4 This will depend on the environment and how the projector is used.
